Hydraulic Press Brake 100 Ton
In StockThe Hydraulic Press Brake 100 Ton is a powerful and high-precision sheet metal bending machine designed for heavy-duty bending operations. Driven by a robust hydraulic system, it delivers smooth, controlled, and consistent bending force to form metal sheets into accurate angles and complex shapes with excellent repeatability.
Built with a strong and rigid frame structure, this machine ensures superior stability, minimal vibration, and long service life during continuous industrial use. It is widely used in sheet metal fabrication workshops, automotive component manufacturing, electrical panel production, and heavy engineering industries.
Hydraulic Press Brake 100 Ton
In Stock
The Hydraulic Press Brake 100 Ton is a powerful and high-precision sheet metal bending machine designed for heavy-duty bending operations. Driven by a robust hydraulic system, it delivers smooth, controlled, and consistent bending force to form metal sheets into accurate angles and complex shapes with excellent repeatability.
Built with a strong and rigid frame structure, this machine ensures superior stability, minimal vibration, and long service life during continuous industrial use. It is widely used in sheet metal fabrication workshops, automotive component manufacturing, electrical panel production, and heavy engineering industries.
Product Specification
Capacity:
Bending: 02 mm to 25 mm Bending.
Length: 1250 mm to 7000 mm.
Standard Accessories:
Variable Stroke Adjustment with Limit Switch
Standard Tooling Set (V-Block & Punch)
Emergency Stop Push Button
Movable Operating Panel with Foot Switch
Front Sheet Support
Lubrication System - Centralized lubrication systems.
Manual Back Gauge
Operation and Maintenance Manual Book
Material test reports.
Machine test reports.
Warranty certificates.
Separate model numbers.
Optional Accessories:
Gooseneck punch
NC Controller
DRO, Motorized Back Gauge.
Motorized Back Gauge.
CNC 2 Axis Back Gauge.
Oil 68 Grade.
Front table for sheet storage.
NC Features. (Optional)
Facilities:
1.7’’ Touch Display. X & Y axis suitable.
2.NC Controller
3.X & Y Axis controller.
4.Timer belt – X axis, Linear – Y axis.
5.Ac servo drive for fast movement.
6.Ac servo drive: Delta
7.Back gauge length: 600 mm
8.Degree correction facilities.
9.Ball screw gauge, LM Guide & Timer belt.
10.Manual fingers.
11.X axis motorized.
12.50 Program storage capacity (Each program: 50 bend)
13.Controller facilities suitable for 2 Axis working.
