H Type Fixed Body Hydraulic Press Machine
The H Type Fixed Body Hydraulic Press Machine is designed for high-accuracy and heavy-duty pressing applications where maximum stability is required.
Its rigid fixed-body H-frame construction provides excellent strength, balanced load distribution, and minimal deflection, ensuring consistent and precise performance under continuous high-pressure operations.
Powered by a reliable hydraulic system, the machine delivers uniform force, smooth motion, and precise control, making it suitable for bending, forming, straightening, pressing, and deep drawing task.
Manufactured using high-quality materials and precision-engineered components, this machine ensures dependable operation, low maintenance, and long service life.
The H Type Fixed Body Hydraulic Press Machine is widely used in fabrication units, automotive component manufacturing, electrical parts production, and general engineering industries.
H Type Fixed Body Hydraulic Press Machine
The H Type Fixed Body Hydraulic Press Machine is designed for high-accuracy and heavy-duty pressing applications where maximum stability is required.
Its rigid fixed-body H-frame construction provides excellent strength, balanced load distribution, and minimal deflection, ensuring consistent and precise performance under continuous high-pressure operations.
Powered by a reliable hydraulic system, the machine delivers uniform force, smooth motion, and precise control, making it suitable for bending, forming, straightening, pressing, and deep drawing task.
Manufactured using high-quality materials and precision-engineered components, this machine ensures dependable operation, low maintenance, and long service life.
The H Type Fixed Body Hydraulic Press Machine is widely used in fabrication units, automotive component manufacturing, electrical parts production, and general engineering industries.
Product Specification
Capacity:
Bending: 02 mm to 25 mm Bending.
Length: 1250 mm to 7000 mm.
Standard Accessories:
Variable Stroke Adjustment with Limit Switch
Standard Tooling Set (V-Block & Punch)
Emergency Stop Push Button
Movable Operating Panel with Foot Switch
Front Sheet Support
Lubrication System - Centralized lubrication systems.
Manual Back Gauge
Operation and Maintenance Manual Book
Material test reports.
Machine test reports.
Warranty certificates.
Separate model numbers.
Optional Accessories:
Gooseneck punch
NC Controller
DRO, Motorized Back Gauge.
Motorized Back Gauge.
CNC 2 Axis Back Gauge.
Oil 68 Grade.
Front table for sheet storage.
NC Features. (Optional)
Facilities:
7’’ Touch Display. X & Y axis suitable.
NC Controller
X & Y Axis controller.
Timer belt – X axis, Linear – Y axis.
Ac servo drive for fast movement.
Ac servo drive: Delta
Back gauge length: 600 mm
Degree correction facilities.
Ball screw gauge, LM Guide & Timer belt.
Manual fingers.
X axis motorized.
50 Program storage capacity (Each program: 50 bend)
Controller facilities suitable for 2 Axis working.
